Specification
Laser Type
|
LD (Laser Diode)
|
Laser Wavelength
|
650nm
|
Ranging Principle
|
ITOF (Phase Shift)
|
Ranging Scope
|
0.05-80m/100m/120m
|
Measuring Frequency
|
5-10Hz/20Hz Software settable
|
Ranging Resolution
|
1mm or 0.1mm Software settable
|
Ranging Accuracy
|
± 2mm (≤10m); ± 2mm ± 0.05x (D-10m) (>10m D=Distance)
|
Input Voltage
|
3.4V (±0.1V)
|
Communication Interface
|
UART
|
UART Baud
|
9600 bps
|
Communication voltage
|
TTL 3.3 VDC
|
Communication protocol
|
Vendor-specific
|
Dimension
|
37x17x46.47mm
|
Weight
|
21g
|
Operation temperature
|
From -10℃ to 50℃
|
Product Description
1. Features: High precision Stable performance Compact size Flexible installation Easy integration
2. Application: Service robot positioning, Industrial/animal husbandry material level detection, Intelligent garbage classification, Crane driving positioning, Security camera trigger, Parking spot detection, Rangefinder etc.
3. Customized items: Ranging Scope, Communication Interface, Structure design
